A3X車規級石英晶體（AEC-Q200）
A3X系列車規級石英晶體，符合AEC-Q200及IATF16949認證，采用SMD3225工業級封裝，在-40℃~+125℃的標準工作溫度范圍內提供常溫±10ppm的頻率公差。該系列對功能安全與長期可靠性有嚴苛要求的自動駕駛域控制器、ADAS系統、車載服務器及信息安全模塊設計，以卓越的環境耐受性與時鐘穩定性，為汽車高性能、高功率核心單元提供符合功能安全標準的基準時鐘信號。
| 產品系列： | A3X |
| 尺寸 | 3.2×2.5×0.70 |
| 封裝 | SMD3225-4P |
| 頻率范圍 | 8-54MHz |
| 頻率公差 | ±10ppm |
| 頻率穩定性 | ±50ppm |
| 工作溫度 | -40℃ to +125℃ |
| 負載電容[pF] | 6 -20 pF |
| ESR（等效串聯電阻） | 30 - 300 Ω |
- 系列
- 型號
- 規格書
- 產品等級
- 尺寸
- 封裝
- 頻率
- 頻率公差
- 頻率穩定性
- 工作溫度
- 負載電容
- ESR（等效串聯電阻）
- 安裝類型
- 產品狀態
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
- A3X
- SX3B27.000F1210G30
- —
- 3.2×2.5×0.70
- SMD3225-4P
- 27MHz
- ±10ppm
- ±30ppm
- -40℃ to +105℃
- 12pF
- 30Ω
- Surface Mount
- Active
-
-
源頭廠家23年元老級企業
自2003年創立，擁有河源國家級高新產業園11,000㎡萬級凈化工廠，實現晶片切割→鍍膜→封焊全鏈自主生產，年產能超3.6億顆，通過ISO 9001/14001、IATF 16949車規認證，獲評國家高新技術企業、專精特新企業。
-
-
品質優勢軍工級品控，極限驗證
15項國家專利，掌握離子刻蝕微調/真空封焊核心技術，IATF16949體系認證，通過AEC-Q200車規測試，通過三重可靠性測試，溫度沖擊（-55℃↔125℃）/機械振動/96h鹽霧，全流程SPC管控，不良率＜0.02%。
-
-
定制優勢敏捷響應，全場景覆蓋
智能電網抗干擾/醫療設備低相噪等12類場景方案，15項國家專利，支持25~200MHz全頻段客制化，全系符合RoHS/REACH指令，提供SGS環保報告，可降解封裝材料（PLA基），助力客戶ESG評級提升，低相噪振蕩器（-149dBc/Hz），滿足生命監護設備時序精度。
-
-
服務優勢全球網絡，終身護航
免費提供《晶振選型白皮書》，降低客戶開發成本30%，F(xiàn)AE團隊24小時響應，電路匹配測試/失效分析，物流服務48小時全球發貨珠三角次日達，歐美亞海外倉直達。
